157B5130 - PVP OC MODULE PVG 32 WITH Pp AND EXTERNAL T0 PORTS - DANFOSS

Danfoss PVP Open Center pump side module for PVG 32 proportional valve groups, dedicated to fixed displacement pumps. External T0 port with option to connect to internal tank, separate Pp port for independent pilot supply. Integrated pilot oil supply for PVE electrical actuation. Compatible with PVG 16 and PVG 32.

Price available only for registered users

Why choose the Danfoss PVP OC module with T0 for PVG 32?

  • Open Center — free pump flow to tank at neutral position, for fixed displacement pumps
  • External T0 port — separate pilot drain line from main T line, ideal for systems with high back pressure on tank line
  • T0 connectable to internal tank — configuration flexibility for different system layouts
  • Separate Pp port — allows independent external pilot supply for advanced configurations
  • Integrated pilot oil supply — correct pilot pressure for PVE electrical actuation of work sections
  • Compatible with PVB 32 work sections — direct integration into the PVG 32 valve group

Key technical data:

  • Code No.: 157B5130
  • Type: PVP Open Center — fixed displacement pumps
  • Port Pp: Separate pilot supply
  • Port T0: External — connectable to internal tank
  • Pilot supply: Integrated for PVE electrical actuation
  • Compatibility: PVG 16 / PVG 32

Typical applications: Agricultural machinery, construction vehicles and mobile systems with PVG 32 and fixed displacement pump where a separate pilot drain line or external pilot supply is required

157B5130
Danfoss
