11223965 - PLUS+1 TOUCH DISPLAY 10.1" DM1000T-0-0-2-0 - DANFOSS

The Danfoss DM1000T-0-0-2-0 is a 10.1" PLUS+1® touchscreen display for mobile off-highway machines, featuring a 1280×800 IPS panel, 900 cd/m² brightness, anti-reflection optical bonding and oleophobic coating. This variant includes 1 × 8-button backlit keypad + navigation panel (16 keys total) and multi-touch screen usable with gloves. Dual core 800 MHz i.MX6 processor, 4 CAN ports, 4 camera inputs, Ethernet, USB and RS232. IP66/IP67 protection front and rear. Weight: 2.528 kg.

Price available only for registered users

Why choose the Danfoss PLUS+1® DM1000T display?

• Market-leading sunlight viewability — 900 cd/m² brightness, optical bonding, anti-reflection, anti-glare treatment and oleophobic coating on a 1280×800 IPS panel with ±85° horizontal and vertical viewing angles

• Water-resistant multi-touch screen — usable with work gloves; integrated accelerometer for automatic rotation between portrait and landscape orientations

• Full connectivity for advanced control architectures: 4 CAN ports, RS232, high-speed USB 2.0, Ethernet, 4 camera inputs (up to 2 displayed simultaneously), audio line-out for vehicle speaker system

• Programmable in PLUS+1® GUIDE with Qt framework support — direct integration with PLUS+1® SC/MC controllers and the full Danfoss HMI product range

• Fast start-up, integrated real time clock, ambient light sensor for automatic brightness adjustment, 32 MB app log and integrated media player (PDF, JPG, MP3, MP4)

Model code decoder DM1000T-0-0-2-0:

• DM1000T → 10.1" display with touchscreen

• 0 → Not configured

• 0 → Not configured

• 2 → Button configuration: 1×8 buttons + navigation panel (16 keys total)

• 0 → No additional software features

Main technical data:

• Part number: 11223965

• Processor: Dual core 800 MHz i.MX6

• RAM: 512 MB — FRAM: 32 kB — Flash: 4 GB

• Screen: 10.1" IPS, 1280×800, 16:10 widescreen

• Brightness: 900 cd/m² — Contrast ratio: 500:1

• Viewing angle: ±85° vertical and horizontal

• Color depth: 24 bit

• Touch: Multi-touch, water and glove resistant

• Buttons: 1×8 backlit + navigation panel (16 total)

• Power supply: 9 ÷ 36 Vdc

• Connectors: 2× DEUTSCH DTM06-12S (C1 + C2)

• CAN ports: 4 (CAN0 ÷ CAN3)

• Other I/O: RS232, USB 2.0, Ethernet, audio line-out, sensor supply, digital/analog/multifunction inputs, wake-up input

• Camera inputs: 4 (max 2 displayed simultaneously) — M12 5-pin connectors

• LEDs: 2× optical RGB for operator signalling

• Ambient light sensor: integrated (automatic brightness adjustment)

• Accelerometer: integrated (auto-rotation portrait/landscape)

• Protection rating: IP66 and IP67 (front and rear)

• Operating temperature: -30 °C ÷ +70 °C [-22 °F ÷ +158 °F]

• Storage temperature: -40 °C ÷ +85 °C

• Vibration: IEC 60068-2-64 (3.17 g) — Shock: IEC 60068-2-27 (50 g)

• EMI/RFI: ISO 13766

• Certifications: CE, UKCA — E-Mark pending

• Weight: 2.528 kg [5 lb 9 oz]

• Dimensions: 260.20 × 192.60 mm (with buttons)

Typical applications: Main operator interface on earthmoving machinery, precision agricultural vehicles, forestry machines and lifting equipment fitted with PLUS+1® control systems; on-board camera display, field mapping navigation and advanced telematics systems.

*Image is for illustrative purposes only
