111.12.029.0A - GEAR PUMP GR1 SKP1NN 4.3 CC/REV - DANFOSS

Danfoss SKP1NN Group 1 external gear pump, 4.3 cc/rev fixed displacement, anti-clockwise rotation, 250 bar rated pressure. SAE A 2-bolt flange, reinforced SAE splined shaft (FA), metric female ports. SKP1 version with larger shaft diameter than SNP1 — designed for high-torque applications and elevated radial shaft loads.

Price available only for registered users

Orders placed from 08-04-2026 to 08-23-2026 will be shipped from 08-24-2026

Why choose the Danfoss SKP1NN Group 1 pump?

  • Larger shaft diameter than the SNP1 series — superior torque transmission, ideal for applications with high radial and axial shaft loads
  • SAE splined shaft (FA) — high-torque mechanical connection for direct PTO and compact gearbox drives
  • Anti-clockwise rotation (L) — specific configuration for installations requiring reverse rotation from standard
  • Pressure-balanced design — high volumetric efficiency and minimal wear across the full operating range
  • Extruded aluminium body — lightweight and structurally robust for harsh environments
  • Case-hardened steel gears — protection against wear, abrasion and fluid contamination
  • SKP1 displacement range: 1.2 / 1.7 / 2.2 / 2.6 / 3.2 / 3.8 / 4.3 / 6.0 / 7.8 / 10 / 12 cc/rev

Model code breakdown SKP1NN/4,3LN02FAP1C2C2NNNN/NNNNN:

  • SKP1NN → Group 1 gear pump — reinforced larger diameter shaft
  • 4,3 → 4.3 cc/rev displacement
  • L → Anti-clockwise rotation (viewed from shaft)
  • N → No integral pressure relief valve
  • 02 → SAE A flange — 2-bolt
  • FA → SAE splined shaft — high torque
  • P1 → Single shaft seal
  • C2/C2 → Metric female ports — inlet/outlet
  • NNNN/NNNNN → Standard configuration

Key technical data:

  • Code No.: 111.12.029.0A
  • Model: SKP1NN/4,3LN02FAP1C2C2NNNN/NNNNN
  • Group: GR1 (Group 1)
  • Series: SKP1 — reinforced shaft
  • Displacement: 4.3 cc/rev
  • Rated pressure: 250 bar [3,625 psi]
  • Maximum pressure: 270 bar [3,915 psi]
  • Maximum speed: ~4,000 rpm
  • Minimum speed: ~800 rpm
  • Theoretical flow at 1,500 rpm: ~6.5 l/min
  • Theoretical flow at 2,000 rpm: ~8.6 l/min
  • Rotation: Anti-clockwise (viewed from shaft)
  • Flange: SAE A — 2-bolt
  • Shaft: SAE splined (FA) — larger diameter
  • Ports: C2 metric female
  • Shaft seal: Single
  • Fluid: Mineral hydraulic oil

Typical applications: Hydraulic steering, auxiliary and pilot circuits on compact vehicles with high-torque PTO, agricultural tractors, light construction machinery with elevated radial loads on the pump shaft

111.12.029.0A
Danfoss
