11034661 – OLSP 80 PRIORITY VALVE – DANFOSS

Danfoss OLSP 80 pump-mounted priority valve, direct flange mount on gear pump. Maximum flow 80 l/min, designed for load-sensing steering systems with Danfoss SNP gear pumps. Always ensures steering circuit priority — compatible with OSPC LS, OSPF LS, OSPD LS and OSPQ LS steering units in both static and dynamic systems.

Price available only for registered users

Why choose the Danfoss OLSP 80 priority valve?

  • Direct flange mount on Danfoss SNP gear pump — compact solution with no intermediate connections, zero connection leakage
  • Always prioritises the steering circuit — primary vehicle safety guaranteed even under critical flow conditions
  • Available in static and dynamic versions — adaptable to any LS steering system configuration
  • Low pressure drop — optimal energy efficiency and reduced fuel consumption
  • Direct integration within the Danfoss range — compatible with OSPC LS, OSPF LS, OSPD LS and OSPQ LS steering units
  • Over 300 priority valve variants in the Danfoss range — maximum application flexibility

Key technical data:

  • Code No.: 11034661
  • Model: OLSP 80
  • Type: 3-way priority valve — pump-mounted (direct flange on gear pump)
  • Maximum flow: 80 l/min [21.1 US gal/min]
  • Max pressure port P: 350 bar [5,076 psi]
  • Max pressure port CF (steering): 210 bar [3,045 psi]
  • Max pressure port EF (excess flow): 350 bar [5,076 psi]
  • LS signal: Static or dynamic
  • Mounting: Direct flange on Danfoss SNP gear pump

Compatibility: Danfoss SNP gear pumps — OSPC LS, OSPF LS, OSPD LS, OSPQ LS steering units in static and dynamic load-sensing systems

Typical applications: Agricultural vehicles, tractors, construction machinery, forklifts, industrial and special vehicles with low-to-medium flow load-sensing steering systems
