11217428 - HMR CAN ROTARY JOYSTICK HMR-111-00-1-0-0-0-0 PLUS+1 - DANFOSS

The Danfoss HMR-111-00-1-0-0-0-0 is a PLUS+1® CAN rotary joystick for operator interface management on mobile machines. Featuring 7 configurable RGB backlit buttons, a Hall effect rotary dial with 32 detents/revolution and integrated push button, and CAN J1939 communication, it enables blind-operation navigation without diverting attention from the task. This variant is configured with no button graphics (blank) and no logo. IP66/IP67 protection, operating temperature -40 °C ÷ +85 °C. Weight: 0.159 kg.

Price available only for registered users

Why choose the Danfoss PLUS+1® HMR rotary joystick?

• Blind-operation navigation — 7 RGB backlit buttons bring screen navigation directly under the operator's fingertips, eliminating the need to reach for displays or touchscreens during machine operation

• Contactless Hall effect rotary dial — 32 detents/revolution with integrated push button and RGB LED backlight at the base; long service life guaranteed by 1 million cycles for both buttons and rotary dial

• Fully CAN-configurable RGB LEDs: button backlights, indicator bars and rotary light — all RGB with adjustable intensity for optimal visual feedback in any lighting condition

• Native PLUS+1® GUIDE integration — fully configurable within the Danfoss development environment for complete customization of functions, icons and LED behaviour

• Rugged construction for harsh environments: IP66/IP67, 50g shock, 7.67g vibration (IEC 60068-2), CE and E1 E-Mark compliant (pending)

Model code decoder HMR-111-00-1-0-0-0-0:

• HMR → HMR CAN Rotary Joystick, PLUS+1® HMI Peripherals

• 111 → Indicator bar, button backlight and rotary knob LEDs (RGB)

• 00 → HMR version 0

• 1 → Standard ring-style rotary knob

• 0 → No logo on knob

• 0 → No button graphics (blank)

• 0 → No special software features

• 0 → No hand-rest

Main technical data:

• Part number: 11217428

• Processor: ARM Cortex M3, 32-bit, 120 MHz

• RAM: 64 kB — EEPROM: 32 kB

• Power supply: 9 ÷ 36 Vdc

• Connector: DEUTSCH DT04-4 pin (CAN Hi/Lo + power)

• Protocol: CAN J1939

• Buttons: 7 × RGB backlit, configurable — 1 million cycle life

• Rotary dial: Hall effect, 32 detents/revolution + integrated push button — 1 million cycle life

• LEDs: RGB on buttons, indicator bars and rotary — CAN-adjustable intensity

• Protection rating: IP66 and IP67 (with mating connector attached)

• Operating temperature: -40 °C ÷ +85 °C [-40 °F ÷ +185 °F]

• Storage temperature: -40 °C ÷ +85 °C

• Vibration: IEC 60068-2-64 (7.67 g) — Shock: IEC 60068-2-27 (50 g)

• EMI/RFI: 100 V/m

• Humidity: IEC 60068-2-78, 60068-2-30

• Transients: ISO 7637/1, 2, 3

• Max mounting torque: 4.5 N·m [40 in·lb]

• Weight: 0.159 kg [0.351 lb]

• Dimensions: 96.44 × 88.96 × 62.00 mm

Typical applications: Operator interface management on earthmoving machinery, agricultural vehicles, forestry machines and lifting equipment fitted with Danfoss DM430E displays or PLUS+1® systems; configuration as hot keys for rapid screen navigation or direct machine function control.

*Image is for illustrative purposes only

11217428
Danfoss
