11244762 - PLUS+1 MICROCONTROLLER XL104-0000 104 PIN 48/40 I/O - DANFOSS

The Danfoss PLUS+1® XL104-0000 is a high pin count microcontroller for advanced management of complex mobile machines. With 104 total pins (48 inputs + 40 outputs), an AURIX 32-bit 200 MHz processor with Lock Step Core and SIL2 compliance, it delivers processing power and functional safety for high-end machine control architectures. Programmable in PLUS+1® GUIDE or C Open, with 3 ISOBUS-certified CAN 2.0B ports, IP67 and thermal range -40 °C ÷ +85 °C. Weight: 0.675 kg.

Price available only for registered users

Why choose the Danfoss PLUS+1® XL104-0000 microcontroller?

• Maximum pin count in the XL range — 104 total pins (48 inputs + 40 outputs) across 3 DEUTSCH connectors (1× DTP 4-pin + 2× DRC 50-pin) for controlling machines with extremely complex I/O architectures

• AURIX 32-bit 200 MHz processor with Lock Step Core and SIL2 compliance — ideal architecture for safety-related applications on mobile off-highway machines requiring processing redundancy and integrated diagnostics

• 3 ISOBUS-certified CAN 2.0B ports — native support for ISOBUS, J1939 and proprietary PLUS+1® protocols for direct integration with displays, joysticks, system controllers and third-party components

• Programmable in PLUS+1® GUIDE (graphical icons) or C Open (C code) — same development environment as the entire PLUS+1® family, with integrated application downloader and diagnostic tools

• 64 MB external flash vault for application logs, parameters and field firmware updates; 32 kB non-volatile EEPROM for persistent data

Main technical data:

• Part number: 11244762 — Order code: XL104-0000

• Processor: AURIX 32-bit, 200 MHz, Lock Step Core

• Internal flash: 2.5 MB — RAM: 240 kB — EEPROM: 32 kB — External flash vault: 64 MB

• A/D converter: 12 bit

• Power supply: 7 ÷ 36 Vdc (internally monitored)

• Sensor power: 1× 5 Vdc fixed / 1× 3 ÷ 12 Vdc variable (500 mA each)

• Total inputs: 48

  - 20× DIN (configurable pull up/down)

  - 4× DIN/AIN/FreqIn (0 ÷ 5.25 V / 0 ÷ 36 V / 1 Hz ÷ 10 kHz)

  - 4× DIN/AIN/FreqIn/Rheo/4-20 mA (6 Ω ÷ 10 kΩ / 0.1 ÷ 28 mA)

  - 17× DIN/AIN (0 ÷ 5.25 V or 0 ÷ 36 V)

  - 3× DIN/AIN/CAN shield

• Total outputs: 40

  - 14× DOUT 3 A (source only)

  - 6× DOUT 4 A (source only)

  - 12× PWM/DOUT/PVGOUT 3 A (33 ÷ 4,000 Hz, open/closed loop with current control)

  - 8× PWM/DOUT/PVGOUT 3 A (33 ÷ 4,000 Hz or 20 kHz, Safety FET Support)

• Max sourcing current: 40 A at 70 °C / 20 A at 85 °C

• Max sinking current: 20 A at 70 °C / 12 A at 85 °C

• CAN ports: 3× CAN 2.0B (all ISOBUS certified)

• Functional safety: SIL2 compliant

• Connectors: 1× DEUTSCH DTP 4-pin (power) + 2× DEUTSCH DRC 50-pin (C1 + C2)

• Protection rating: IP67 (with mating connectors attached)

• Operating temperature: -40 °C ÷ +85 °C [-40 °F ÷ +185 °F]

• Storage temperature: -55 °C ÷ +85 °C

• Vibration: IEC 60068-2-64 — Shock: IEC 60068-2-27

• EMI/RFI: 150 V/m

• Dimensions: 221.91 × 198.18 × 53.50 mm

• Weight: 0.675 kg [1.48 lb]

Typical applications: Primary control of high-complexity earthmoving machines, precision agricultural vehicles with ISOBUS, hydraulic cranes, forestry machines and any off-highway system requiring high I/O count, SIL2 functional safety and native integration with the Danfoss PLUS+1® ecosystem.

*Image is for illustrative purposes only
