11010067 - STEERING UNIT OSPC 70 ON - DANFOSS

Danfoss OSPC 70 ON hydrostatic steering unit, 70 cc/rev displacement, open center non-reaction type. No mechanical connection between steering wheel and steered wheels — fully hydraulic control. Steering torque from 0.8 to 3.0 Nm, maximum pressure 210 bar, max back pressure 40 bar. Designed for off-road vehicles, agricultural and industrial machines with fixed displacement pump steering systems.

Price available only for registered users

Why choose the Danfoss OSPC 70 ON steering unit?

  • Pure hydrostatic system — no mechanical link between steering wheel and wheels, maximum vehicle layout freedom
  • Open Center Non-Reaction (ON) type — in neutral position flow circulates freely to tank; external forces on steered wheels are not transmitted to the steering wheel
  • Low steering torque: 0.8–3.0 Nm — light and precise steering even under high load conditions
  • Low noise level — superior operator comfort
  • Low pressure drop — optimal energy efficiency
  • Integrable valve functions: pressure relief, shock valves, suction valves, check valve in P — maximum application flexibility
  • Over 1,800 variants available in the Danfoss range — adaptable to any vehicle configuration

Key technical data:

  • Code No.: 11010067
  • Model: OSPC 70 ON
  • Type: Hydrostatic steering unit — open center non-reaction
  • Displacement: 70 cc/rev
  • Maximum steering pressure: 210 bar [3,045 psi]
  • Maximum back pressure: 40 bar [580 psi]
  • Steering torque: 0.8–3.0 Nm (normal conditions)
  • System: Open Center — fixed displacement pump
  • Port connections: Standard ISO threads

Typical applications: Agricultural machinery, tractors, construction vehicles, forklifts, earthmoving machines, industrial and special vehicles with hydrostatic steering systems

11010067
Danfoss
