084Z8019 - TEMPERATURE SENSOR MBT 5250-0000-080-230 - DANFOSS

Danfoss MBT 5250 insertion temperature sensor, 80 mm length, NPT 1/2-14 process connection, Pt 100 element, angular Pg 11 connector, IP65 protection. Operating range -50°C / +200°C, AISI 316 Ti stainless steel protection tube. Designed for harsh industrial environments with interchangeable sensor insert — no system shutdown required for replacement.

Price available only for registered users

Why choose the Danfoss MBT 5250 sensor?

  • Interchangeable sensor insert — fast replacement without stopping or emptying the system
  • Pt 100 element — reliable and accurate measurement across the full operating range
  • AISI 316 Ti stainless steel protection tube — maximum resistance to corrosion and aggressive fluids
  • IP65 protection — resistant to dust and water jets
  • NPT 1/2-14 process connection — ANSI/ASME B1.20.1 standard, ideal for plants with American thread fittings
  • 8 mm tube diameter — compact design for confined spaces
  • Approvals available for marine and air compressor applications

Key technical data:

  • Code No.: 084Z8019
  • Model: MBT 5250-0000-080-230
  • Type: Insertion temperature sensor with interchangeable insert
  • Sensor technology: Pt 100
  • Insertion length: 80 mm
  • Protection tube diameter: 8 mm
  • Protection tube material: AISI 316 Ti stainless steel
  • Process connection: NPT 1/2-14 (ANSI/ASME B1.20.1)
  • Electrical connection: Angular connector Pg 11
  • Enclosure rating: IP65
  • Temperature range: -50°C / +200°C

Typical applications: Air compressors, HVACR systems, oil and industrial fluid temperature monitoring, mobile hydraulics, engine cooling systems, marine applications
