11006593 - PRIORITY VALVE OLS 320 - DANFOSS

Danfoss OLS 320 priority valve for high-flow load-sensing steering systems. Maximum flow 320 l/min, dynamic LS signal with 7 bar setting, G1'' P port connection. Always ensures steering circuit priority over other circuits — primary safety function for industrial, agricultural and construction vehicles. Compatible with Danfoss static and dynamic LS orbitrols

Price available only for registered users

Why choose the Danfoss OLS 320 priority valve?

  • Always prioritises the steering circuit — vehicle safety is never compromised even under critical flow conditions
  • Dynamic LS signal — fast response to steering demand variations, minimal pressure drop
  • Maximum flow 320 l/min — suitable for machines with high-flow pumps and large-scale systems
  • Low pressure drop under normal operating conditions — improved energy efficiency and reduced fuel consumption
  • Line-mounted design — simple and versatile installation on any hydraulic layout
  • Compatible with Danfoss static and dynamic LS orbitrols — guaranteed integration within the Danfoss range

Key technical data:

  • Code No.: 11006593
  • Model: OLS 320
  • Type: 3-way priority valve with LS control
  • Maximum flow: 320 l/min [84.5 US gal/min]
  • Maximum system pressure: 350 bar [5,076 psi]
  • LS signal: Dynamic — 7 bar setting
  • Static LS orifice: Ø 1.2 mm
  • Dynamic LS orifice: Ø 1.0 mm
  • Port P (inlet): G 1''
  • Port CF (priority/steering): G 1/2
  • Port EF (excess flow): G 1
  • Port LS: G 1/4
  • Port T (tank): G 1/4
  • Mounting: Line mounted

Compatibility: Danfoss orbitrols with static and dynamic LS signal — OSPB, OSPC, OSPF series and compatible units

Typical applications: Agricultural vehicles, construction machinery, industrial and earthmoving vehicles, high-flow load-sensing hydraulic steering systems

11006593
Danfoss
