11057525 - IDROGUIDA OSPC 160 ON - DANFOSS

11057525 - IDROGUIDA OSPC 160 ON - VERNICIATO NERA

Model code: OSPC##-0160-ON##-GGGG-E-M-N-N-N-125-180-1-1-N02-SP2-G01-NN-DNFS-PB

Characteristic	Value	Description
Anti-cavitation Valve	1	Suction/Anti-cavitation Valves Present
Check Valve for P and LS line	1	Check valve in P-port
Circuit Type		ON
Gear Set Displacement Size	0160	160cc single displacement
LS Port Connection Size	N	No Load Sensing [LS]
LS Port Location	N	No LS or EF port
LS Port Thread Specification	N	No Load Sensing [LS]
Painting	PB	Black, Corrosion class C3. Standard covering
Product Label	DNFS	Standard Danfoss Label
Pump Tank Left and Right Servo Port Connection Size	GGGG	Pump, Tank, Left & Right (PTL&R) = G1/2"
Pump Tank Left and Right Servo Port Thread Specification	E	BSP (G-thread): Spot-face
Relief Valve Pressure Setting	125	125-130 BAR [1813-1885 psi]
Shock Valve Pressure Setting	180	180-200 BAR [2610-2900 psi]
Special features	NN	No special features (standard)
Spool/Sleeve Set	SP2	OSP ON3 - noise reduced - 10-30 [l/min]
Spool/Sleeve Set Centering Springs,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,	N02	0.9-4.5 [Nm] - Hard 1 (150N4035)
Standard or 'Low-Noise' Gearset & Sealed Star	G01	Low-Noise
Steering Column Connection Interface Thread-type	M	4x M10x1.5 bolt holes for column connection
