S3000-1890-1N00-1C-0 - MOTORE S3000 - BLACK BRUIN
zoom_out_map
chevron_left chevron_right
Contattaci per questo prodotto Non hai trovato quello che cercavi?

S3000-1890-1N00-1C-0 - MOTORE S3000 - BLACK BRUIN

 Model Code Description

  • Frame: S3000
  • Displacement: 18900 ccm/rev
  • Displacement Control: 1-speed, Fixed displacement
  • Shaft type: DIN5480-N150
  • Housing type: M24 threads
Quantità Sconto unità Salva
2 20% 33.677,51 €
4 44% 148.181,06 €

Per completare il tuo acquisto Registrati

Displacement
at full displacement
at half displacement
18900 cm
-
Maximum torque
theoretical
with 100 bar
135000 Nm
30100 Nm
Brake Torque
Max. Operating Power
at full displacement
at half displacement
500 kW
-
Max. Rotating Speed
at full displacement
at half displacement
at freewheeling
60 rpm
-
180 rpm
Min. Rotating Speed (constant running) 3 rpm
Rotating Direction
flow direction A to B
Flow direction B to A
CW
CCW
Max. Working Pressure
peak pressure
intermittent ¹⁾
450 bar
450 bar
Max. Case Pressure
average
intermittent ¹⁾
2 bar
10 bar
Pilot Pressure for 2-Speed Valve
at full displacement
Y1
Y2
at half displacement
Y1
Y2
Brake Opening Pressure
minimum
maximum
Flushing Flow
recommended
maximum
7,6 - 9,5 l/min
15 l/min
Fluid Viscosity
recommended
minimum
25 - 50 cSt
15 cSt
Operating Temperature
recommended
maximum
< 70° C
85° C
Weight 665 Kg
Tightening Torque housing interface ²⁾ ³⁾ 930 Nm M24x3 10.9
S3000NM00049
Black Bruin
